Bambu Pla Aero White

Specification :

Cautions for Use :

• Recommended to dry out before use
• All AMS Series Compatible

Bambu PLA Aero

Bambu PLA Aero achieves low density and light weight by foaming at high temperatures during printing and creating small holes inside the prints. It's the perfect choice for light-weight and energy-saving prints, including unmanned aerial vehicles (UAVs), aerodynamic models, and gliders.

Foaming PLA materials (PLA Aero) have high requirements for material drying and parameter settings.

When printing models of the same volume, PLA Aero is about half the weight of PLA Basic.

Controllable Model Density



Achieve lower density of the prints by increasing printing temperature and lowering flow rate.





	Parameter Setting	Average Density
Printing Temperature	Increases ↗	Decreases ↘
Printing Speed	Increases ↗	Stable or Increases ↗
Flow Rate Ratio	Increases ↗	Increases ↗
Model Size	Increases ↗	Decreases ↘
Wall Thickness（Wall loops）	Increases ↗	Increases ↗
Infill Density	Increases ↗	Increases ↗



The relationship between the maximum foaming rate, minimum print density, and printing temperature of PLA Aero.



Printing Temperature	Minimum Flow Rate Ratio	Maximum Volumetric Expansion Ratio	Maximum Foaming Rate	Minimum Prints Density
190 °C	~ 0.95	~ 100%	~ 0%	~ 1.17 g/cm³
200 °C	0.89	110%	10%	1.06 g/cm³
210 °C	0.85	115%	15%	1.02 g/cm³
220 °C	0.76	129%	29%	0.91 g/cm³
230 °C	0.62	158%	58%	0.74 g/cm³
240 °C	0.45	217%	117%	0.54 g/cm³
250 °C	0.38	258%	158%	0.45 g/cm³
260 °C	0.35	280%	180%	0.42 g/cm³
270 °C	0.37	265%	165%	0.44 g/cm³



Matte Finish For Easy Coloring

Bambu PLA Aero provides an easy-to-color matte surface texture with better dyeing results as compared to PLA Basic.



Accessory Compatibility

	Recommended	Not Recommended
Build Plate	Cool Plate SuperTack, Smooth PEI Plate, Textured PEI Plate	/
Hotend	Hotend with Hardened Steel Nozzle 0.4 mm Hotend with Stainless Steel Nozzle 0.4 mm	Hotend with Hardened Steel Nozzle 0.6 mm / 0.8 mm Hotend with Stainless Steel Nozzle 0.2 mm
Glue	Bambu Liquid Glue Glue Stick	/



Recommended Printing Settings
Drying Settings (Blast Drying Oven)	55 °C，8 h
Printing and Keeping Container's Humidity	< 20% RH (Sealed, with Desiccant)
Nozzle Temperature	220 - 260 °C
Bed Temperature (with Glue)	35 - 45 °C
Printing Speed	< 180 mm/s



Physical Properties
Density	1.21 g/cm³
Vicat Softening Temperature	54 °C
Heat Deflection Temperature	53 °C
Melting Temperature	153 °C
Melt Index	7.7 ± 0.6 g/10 min



Mechanical Properties
Tensile Strength	24 ± 2 MPa
Breaking Elongation Rate	2.6 ± 0.7 %
Bending Modulus	1690 ± 120 MPa
Bending Strength	45 ± 4 MPa
Impact Strength	28.8 ± 1.3 kJ/m²
